5V0-23.20 VMware vSphere with Tanzu Specialist Questions and Answers

Tanzu Kubernetes Cluster is a Kubernetes cluster deployed by developers using a YAML specification file. It uses resources from hosts across vSphere clusters to form a Kubernetes cluster on vSphere. It also enables vSphere High Availability and Distributed Resource Scheduler, which allows for load balancing and high availability of resources in the cluster. It does not remove the Kubernetes API for use by DevOps teams.

https://docs.vmware.com/en/VMware-vSphere/7.0/vmware-vsphere-with-tanzu/GUID-1238AFD8-232C-4EFC-BD54-796CB9F8C45F.html

Resource Name Description

configmaps The total number of ConfigMaps that can exist in the namespace.

persistentvolumeclaims The total number of PersistentVolumeClaims that can exist in the namespace.

pods The total number of Pods in a non-terminal state that can exist in the namespace. A pod is in a terminal state if .status.phase in (Failed, Succeeded) is true.

replicationcontrollers The total number of ReplicationControllers that can exist in the namespace.

resourcequotas The total number of ResourceQuotas that can exist in the namespace.

services The total number of Services that can exist in the namespace.

services.loadbalancers The total number of Services of type LoadBalancer that can exist in the namespace.

services.nodeports The total number of Services of type NodePort that can exist in the namespace.

secrets The total number of Secrets that can exist in the namespace.

• VM storage policies are translated into Kubernetes storage classes.

• Developers can access all assigned VM storage policies in the form of storage classes. •

Developers cannot manage storage classes.

Graphical user interface Description automatically generated

The vSphere administrator defines and assigns VM storage policies to a namespace:

• VM storage policies are translated into Kubernetes storage classes.

• Developers can access all assigned VM storage policies in the form of storage classes.

• Developers cannot manage storage classes.

Storage class names are created in the following way:

• Spaces in VM Storage Policy names are replaced with hyphens (-).

• Special characters are replaced with a digit. A VM Storage Policy called My Gold Policy $ is called my-gold-policy-0 as a storage class.

Graphical user interface, application Description automatically generated

Permissions for programmers should be assign at the Namespace level, typically using groups and roles.

You assign roles for the Namespace to Active Directory groups. You can later assign access to users by adding them to these groups. You assign access to separate Active Directory groups for the edit and view roles in the Namespace.

External HTTP(S) Load Balancing is a proxy-based Layer 7 load balancer that enables you to run and scale your services behind a single external IP address.

Scale a Cluster Horizontally With the Tanzu CLI

To horizontally scale a Tanzu Kubernetes cluster, use the tanzu cluster scale command. You change the number of control plane nodes by specifying the --controlplane-machine-count option. You change the number of worker nodes by specifying the --worker-machine-count option.
