HP HPE3-U01 Dumps Questions Answers

The PCs are not able to successfully establish bidirectional communication because they are on different subnets and their default gateways are not configured correctly. The default gateway is the IP address of the router interface that connects to the same subnet as the PC. The default gateway allows the PC to send packets to destinations outside its own subnet. In this case, PC-1 and PC-2 are on the 172.16.30.0/24 and 172.16.31.0/24 subnets respectively, and the router interfaces are 172.16.30.254 and 172.16.31.254 respectively. Therefore, the correct default gateway for PC-1 is 172.16.30.254 and the correct default gateway for PC-2 is 172.16.31.254. Changing PC-2’s default gateway to 172.16.31.254 will enable the communication between PC-1 and PC-212 References:

• Aruba Certified Network Technician (ACNT) - HPE Certification and Learning
• Aruba Certified Network Technician (ACNT) - Aruba Networks.

To convert a hexadecimal number to a binary number, we need to follow these steps:

• Write down the hexadecimal number and assign a power of 16 to each digit, starting from the rightmost with 16^0.
• Convert each hexadecimal digit to its decimal equivalent by multiplying it with its power of 16.
• Add all the decimal values to get the decimal equivalent of the hexadecimal number.
• Divide the decimal number by 2 repeatedly and write down the remainders from bottom to top.
• The binary number is the sequence of remainders obtained in the previous step.

Let’s apply these steps to the hexadecimal number 17:

• 17 = 1 × 16^1 + 7 × 16^0
• 17 = 16 + 7
• 17 = 23 in decimal
• 23 / 2 = 11 with remainder 1
• 11 / 2 = 5 with remainder 1
• 5 / 2 = 2 with remainder 1
• 2 / 2 = 1 with remainder 0
• 1 / 2 = 0 with remainder 1
• The binary number is 10111

Therefore, the binary equivalent of the hexadecimal number 17 is 10111 (option B).

References: The answer can be verified by using the following resources:

• Hexadecimal to Binary Converter - Binary Hex Converters
• How to Convert 17 from hexadecimal to binary - Calculator Online
• Convert hexadecimal number 17 to binary - CoolConversion
• 17 in Binary - How to Convert 17 from Decimal to Binary? - Cuemath

ARP is a protocol that maps an IP address to a MAC address, which is the physical address of a device on a network. ARP is necessary because the software address (IP address) of the host or computer connected to the network needs to be translated to a hardware address (MAC address). Without ARP, a host would not be able to figure out the hardware address of another host. ARP works by sending a broadcast message to all devices on the network, asking for the MAC address of the device that has a specific IP address. The device that has that IP address replies with its MAC address, and the sender stores this information in its ARP cache for future use. The sender then uses the MAC address as the destination address of the Layer 2 header that encapsulates the IP packet. The Layer 2 header is also known as the data link layer header, which is responsible for delivering the packet to the correct device on the same network. The Layer 3 header is also known as the network layer header, which is responsible for routing the packet to the correct network. Therefore, the correct answer is C, because ARP is used to discover the destination address of the Layer 2 header that encapsulates IP packets1234 References: What Is Address Resolution Protocol (ARP)? - Fortinet, Address Resolution Protocol - Wikipedia, ARP (Address Resolution Protocol) explained - Study-CCNA, Aruba Certified Network Technician Exam HPE3-U01 Actual Questions
