Netapp NS0-162 Dumps Questions Answers

 The route is a network configuration that defines how the traffic from a LIF is routed to a destination. The route consists of a destination, a gateway, and a metric. The destination is the IP address or subnet that the LIF wants to reach. The gateway is the IP address of the next-hop router that forwards the traffic to the destination. The metric is a numerical value that indicates the preference of the route. In this scenario, the route for the SVM vs0 has a destination of 0.0.0.0/0, which means any IP address or subnet. The gateway is 10.61.208.1, which is the IP address of the router that connects the LIF to the rest of the network. The metric is 20, which is a relatively low value that indicates a high preference. However, the gateway is incorrect, as it does not match the subnet of the LIF. The LIF has an IP address of 192.0.2.130 and a netmask of 255.255.255.0, which means its subnet is 192.0.2.0/24. The gateway should be an IP address within the same subnet, such as 192.0.2.1. This would allow the LIF to communicate with the router and reach other destinations. The incorrect gateway causes connectivity issues, as the LIF cannot find a valid route to send or receive traffic. To resolve this issue, the route needs to be modified to reflect the correct gateway using the network route create or network route modify commands or the System Manager GUI12. References :- Create a route, Modify a route

 To troubleshoot the issue of iSCSI LUNs not visible on the host, you should verify that the iSCSI data protocol has been enabled on the ports and that the controller has not been taken over. If the iSCSI data protocol is disabled on the ports, the storage system will not accept iSCSI connections or requests over those ports. If the controller has been taken over by its partner, the iSCSI LUNs on the taken-over node will not be available to the host. You can use the vserver iscsi connection show command to check the status of the iSCSI connections and the storage failover show command to check the status of the controller. References :- Troubleshoot iSCSI LUNs not visible on the host, vserver iscsi connection show, storage failover show
