Fortinet FCP_FGT_AD-7.4 Dumps Questions Answers

The sniffer output shows that packets from the web client are reaching the FortiGate and being forwarded to the web server, but there is no indication that the web server is responding. To troubleshoot this issue, executing a debug flow will help analyze the traffic path and pinpoint where the problem might be occurring, such as a possible issue in firewall policy or route settings that is causing the server not to respond correctly.

References:

FortiOS 7.4.1 Administration Guide: Troubleshooting network connectivity

The application control engine on a FortiGate next-generation firewall is responsible for identifying and managing application traffic. It allows administrators to set policies based on application types, regardless of the port or protocol being used.

When SD-WAN is enabled on FortiGate, the load balancing algorithm for Equal-Cost Multi-Path (ECMP) is configured using the load-balance-mode parameter under SD-WAN settings. However, if SD-WAN is disabled, the ECMP load balancing algorithm can be configured under config system settings. This flexibility allows FortiGate to control traffic routing behavior based on the network configuration and requirements.

References:

FortiOS 7.4.1 Administration Guide: ECMP Configuration
