The port1 and port2 default routes are active in the routing table

The routes with 0.0.0.0/0 for both port1 and port2 are marked with an asterisk * and > symbol, which indicates that these routes are active and selected in the routing table.

The port3 default route has the highest distance

The route via port3 has a distance of [20/0], which is higher than the distances for the routes via port1 [10/0] and port2 [30/0]. This indicates that the port3 default route has the highest distance.

When SD-WAN is enabled on FortiGate, the load balancing algorithm for Equal-Cost Multi-Path (ECMP) is configured using the load-balance-mode parameter under SD-WAN settings. However, if SD-WAN is disabled, the ECMP load balancing algorithm can be configured under config system settings. This flexibility allows FortiGate to control traffic routing behavior based on the network configuration and requirements.

References:

FortiOS 7.4.1 Administration Guide: ECMP Configuration

When SSL certificate inspection is enabled on a FortiGate device, the system uses the following three pieces of information to identify the hostname of the SSL server:

Server Name Indication (SNI) extension in the client hello message (B): The SNI is an extension in the client hello message of the SSL/TLS protocol. It indicates the hostname the client is attempting to connect to. This allows FortiGate to identify the server's hostname during the SSL handshake.

Subject Alternative Name (SAN) field in the server certificate (C): The SAN field in the server certificate lists additional hostnames or IP addresses that the certificate is valid for. FortiGate inspects this field to confirm the identity of the server.

Subject field in the server certificate (D): The Subject field contains the primary hostname or domain name for which the certificate was issued. FortiGate uses this information to match and validate the server’s identity during SSL certificate inspection.

The other options are not used in SSL certificate inspection for hostname identification:

Host field in the HTTP header (A): This is part of the HTTP request, not the SSL handshake, and is not used for SSL certificate inspection.

Serial number in the server certificate (E): The serial number is used for certificate management and revocation, not for hostname identification.

References

FortiOS 7.4.1 Administration Guide - SSL/SSH Inspection, page 1802.

FortiOS 7.4.1 Administration Guide - Configuring SSL/SSH Inspection Profile, page 1799.
